10.1 inch linux debian rugged tablet 4G LTE 4GB 64GB
linux debian tablet linux debian rugged tablet linux rugged tablet linux industrial tablet
10.1 inch android 7.1 and linux Debian optional RAM/ROM 4GB/64GB 4G LTE/WIFI/GPS/BT/NFC USB 3.0*1, USB2.0*1, Micro USB *1 HDMI, RS232, DC3.5 bottom pogopin, and back pogopin support USB, TTL, 5V and 3.3V output and input 2D barocde N3680 optional UHF M500 optional high precision GPS optional front NFC optional can customize OS and function
| ITEM | DESCRIPTION | detail | Remark | | OS | Linux-debian |
|
| | CPU | RK3399
6 Core 1.8GHz， A72 |
|
| | RAM/ROM | 4GB/64GB |
|
| | LCD | 10.1 inch1920*1200； | 500 nits sunshine readable |
| | Touch screen | 10 point touch, support stylus |
|
| | Camera | 5M/13M, flash | 5M/13M, flash |
| | Power and battery | battery total capacity 10500mAh | 8400mAh,hotswap, 2100mAh backup power
3.8V 3A imput, support hotswap |
| | 3.5*1.35mm, 5V 3A DC in put | Magnetic charger |
|
| | WWAN | 4G LTE, 3G WCDMA, GSM | 4G Fre:
FDD: B1,B2, B3,B5, B7, B8, B12， B20
TDD: B38,B39,B40,B41
B34
WCDMA:B1, B8
TD-SCDMA: B34, B39
GSM/GPRS/EDGE |
| | GPS | baidou,GPS, glonass |
|
| | wifi | 802.11a b c, g,n wireless internet Wireless AP ( Mobile AP )2.4G, 5G |
|
| | BLUETOOTH | 4.0 version |
|
| | NFC | 13.56 MHz, distance 5cm or above |
|
| | SPEAKER | 1.5 watt |
|
| | Sensor | 1. light sensor
2. compass
3. gravity
4. acceleration
5. baroceptor |
|
| | size | 275*178*18mm |
|
| Multi-media
(Hardware decoding) | Photo Viewer | BMP, JPG, GIF, PNG |
| | Video Format | MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) |
|
| | Audio Format | MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license) |
|
| | language | multi language |
|
| interface
in/out port | 1. normal USB*1
2. Micro USB*1
3. RJ45*1
4. bottom pogopin*1, USB and serial
5. back pogopin*1
6. DC*1 3.5*1.35
7. microphone+earphone
8. RS232*1
9. HDMI*1
10.micro SD *1
11.SIM card slot *1 |
|
| | Pogopin definition | 1.16pin back of cover, include （1USB, 1 RS232， 1 UART， 3.3V, 5V OUT)
2. 8pin in bottom； （1USB, 1 RS232， 1 UART， )
VESA hole 75*75mm or 90*90mm |
|
| | casing material | ABS/PC |
|
| | button | V+ -, Power, P, F, H |
|
| | 2D barcode module | honeywell N3680 |
| optional | | UHF | reading and write distance 1meter to 10 meter |
| optional | | fingerprint module | LD-8800-M |
| optional | standard
accessories
in gift box | 1. USB cable
2. charger( 4-in-1)
3. handstrap
4. handstring
5. white box, no logo |
|
| optional
accessories | 1. car docking
2. extra battery
3. screen protective film
4. car holder
5. docking station
6. car charger
|
|
| | proof rate | 1. water proof IP65
2. Drapping proof 1.2 meter |
|
| | Certification | 1. 810G
2. CE,FCC |
|
| | Temperature | 1. storate temperature -25 to 80 degree
2. operation temperature -20 to 60 degree
|
|
|
|
|
